Indoor Laser Shotgun (ILS)

Anyone with a shotgun licence wishing to use Indoor Clay Targets for practice or coaching may bring their own shotgun - if permitted by the venue.

However, most people won't have their own shotgun so a safe alternative is required.

ILS is not a shotun!

ILS is not a "shotgun"

An Indoor Laser Shotgun (ILS):

  • cannot fire projectiles and cannot be converted to a gun - its only task is to send a short pulse of low power infrared laser light to simulate a "shot".
  • meets all the requirements in the UK of sections 36 and 38 of the Violent Crime Reduction Act 2006 as well as subsequent regulations.
  • feels like a real outdoor shotgun - it has the same weight (adjustable) and the same point of balance. The trigger mechanism is designed to give the same "feel" as on a real shotgun.

Indoor Clay Targets:

  • uses a PC data projector to display a photographic background and moving clays onto a wall or screen,
  • sends the laser pulse when the user presses the trigger on the shotgun or ILS,
  • uses the DryFire Sensor Unit (DPS-SU) to detect where the laser pulse hit the wall or screen,
  • carries out calculation to show how far the simulated "shot" was from the clay.

The ILS is designed specifically for use with Indoor Clay Targets with the aim of bringing more people, especially young people, into the sport - not to compete with the beautiful shotguns made by the likes of Perazzi, Krieghoff, Beretta, Guerini, Blaser, Browning, Miroku etc..

A work in progress

We are actively working on the design of the ILS.

We don't have a monopoly on ideas and we welcome positive and creative suggestions from anyone. Please contact us at the email:

Can we learn from the small-bore world?

The .22LR small-bore and air rifle worlds moved towards "anatomical" rifles many years ago and found that such guns were far more attractive to younger shooters than the traditional all wood and steel models. People liked the modern look and the ability to adjust almost everything.

The world has moved from this (a LH BSA Martini International Mk V - super accurate in the prone position):

To this (a System Gemini small-bore rifle):

Or this (a Walther LG400 air rifle):

Or this (a Walther KK300 small-bore rifle):

Tradition is always to be respected ("if it works, don't fix it") and a beautiful shotgun is a work of art, but perhaps the time has come for some creative thinking to appeal to a younger market.

Some manufacturers of high-end competition clay shotguns have started to move towards fully adjustable stocks.

Design background

Shotguns may have a single barrel or two barrels which may be "side by side" or "over and under".

Single barrel shotguns may fire one shot before reloading or they may be "semi-automatic" - they automatically load a second cartridge when the first has been used.

Double barrel shotguns fire the first barrel when the trigger is pressed and the second barrel when it is pressed again. The order in which the barrels are fired (top then bottom or bottom then top) is selectable.

Shotguns come in different "calibres" relating to the diameters of the cartridges and barrels.

The Indoor Laser Shotgun (ILS) will be modelled on an over-and-under 12 bore - in the USA this is referred to as a "12ga" - short for "12 gauge". The diagram below shows the parts of such a shotgun.

The external dimensions of ILS barrels are easy to model and can be made as an aluminium extrusion. The barrels will have an OD of 21.5mm and an ID of 16.5mm.

The forend is also straightforward and can be injection moulded or routed from wood.

The action contains the trigger mechanism and electronics. The ILS does not require an external DryFire Universal Gun Assembly because all the parts are inside the action which will be machined from aluminium.

A key feature of a shotgun is its stock - this is the part that enables a shotgun to be configured for different users. Some people have longer arms than others and getting the correct "length of pull", the distance from the butt plate to the trigger blade, is a very important part of "gun fit".

"Length of pull" may vary between 330mm (13") and 405mm (16") - an adjustment range of 75/80mm at the butt plate.

The stock angles downwards from the back of the action to bring the shooter's eye level with the rib on top of the barrel. The amount of "drop" is defined by distances down from a horizontal line running along the top of the rib. Drop is measured at the front of the comb (usually about 35mm down) in the middle of the comb and at the heel - the top of the butt plate (usually about 54mm down).

The shooter's trigger hand wraps round the "grip" so the pad of the index finger falls neatly onto the trigger blade. Grips may be "handied" for left or right handed use or they may be ambidextrous.

The ILS requires an ambidextrous grip - either injection moulded or CNC milled from wood. The grip will fit round the aluminum stock that fits to the action and is only long enough for the shooter to have a comfortable grip.

The top of the stock, the "comb", fits neatly into the shooter's cheek (the cheek bone is specifically designed for this purpose!) and its height may be adjusted up/down to bring the shooter's eye level with the barrel rib. The ILS comb will be ambidextrous and either injection moulded or CNC milled from wood.

When looking down on a shotgun the stock is not be aligned with the barrel - it will be offset or "cast" to the right or left so the shooter's eye sits central to the barrel without having to roll the head over. If the junction of the stock and action is symmetrical vertically, cast can be adjusted with a simple angled aluminium or steel shim which can be rotated to give left or right cast.

The butt is not square-on to the rest of the stock, it is pitched at an angle between 5 and 6 degrees. The butt plate is often a separate part attached to the butt in such a way that it can be raised up or down and rotated slightly left/right and clockwise/anticlockwise to give the best fit for the shooter.

ILS specifics

Please do not take the sketch below as representing what ILS will look like. It is very crude and designed only to show the building blocks that make up the system. Colours are used to differentiate individual components.

The butt plate, comb, pistol grip and forend could be either wood or synthetic (injection moulded).

All surfaces will blend smoothly into one another on the final version.

From left to right:

  • Butt plate.
  • Aluminium frame to hold butt plate, comb and pistol grip.
  • Ambidextrous comb.
  • Ambidextrous pistol grip.
  • Action: machined from aluminium for the trigger and electronics.

    Alternatively the action and grip could be formed as a single part - as shown below.

  • Shim for adjusting left/right cast angle.
  • Forend.
  • Upper and lower barrels: aluminium extrusion.

    The lower barrel is threaded for stackable stainless steel weights to adjust overall weight and balance..

ILS is designed to provide eight adjustments within the stock:

  • Butt plate up/down.
  • Butt plate rotation.
  • Butt plate left/right.
  • Butt plate in/out (to adjust length of pull)
  • Butt plate tilt.
  • Comb up/down.
  • Comb forwards/backwards.
  • Comb tilt - slope angle.

The stock frame also allows for the addition of counterweights - one is shown fitted.

The right hand side of the frame fits through the pistol grip and into the action.

The sketch below shows how the comb mount may be adjusted up/down, forward/backwards and for tilt.

The sketch below shows the barrel and forend. The laser "fires" through the top barrel and the bottom barrel is threaded for weights and counterweights to adjust the overall weight and balance.

Safety features

  • ILS meets the requirements of sections 36 and 38 of the Violent Crime Reduction Act 2006 as well as subsequent regulations.
  • Aluminium barrel not steel - no breech
  • Internal diameter of barrels too small to accept cartridges.
  • Trigger mechanism designed for only switching the laser on/off.
  • Laser enabled only when a target is about to be taken
  • Stock and barrel may be disassembled from action for storage or transport.

UK regulations require at least 51% of the surface area of a replica firearm to be one of the following colours: bright red, bright orange, bright yellow, bright green, bright pink, bright purple or bright blue.
